Top Ten Differences Between ActiveMQ and Amazon SQS

Taxi queue at LaGuardia Photo credit: Scott Beale / Laughing Squid
Taxi queue at LaGuardia
Photo credit: Scott Beale / Laughing Squid

1. Persistence and Durability

ActiveMQ

Depending on the configuration ActiveMQ can maintain a message journal1. Each message is first written into a journal before being shipped to consumers. Ultimately, the number of messages that can be persisted is constrained by the available disk capacity.

SQS

Amazon SQS stores messages in a distributed storage across all availability zones in a given region2. Each message size can be up to 256KB and SQS can store an unlimited number of messages across unlimited number of queues3.

2. Redundancy

ActiveMQ

ActiveMQ offers a number of different configuration options for clustering4:

  • Broker Clusters and Networks of Brokers: this architecture is most appropriate for distributed networks of brokers. Producers on each broker can reach consumers across the entire cluster. This is most appropriate for a use case such as delivering market data to all consumers across the entire network (JMS topics). This is not exactly a redundant configuration – failure of a single broker results in message loss on that broker.
  • Master-Slave : In this configuration two or more ActiveMQ brokers use some sort of a shared5 storage for the journal. Prior to ActiveMQ 5.9 one had to relied either on a shared file system such as SAN or on an SQL database – which simply shifted the replication responsibility to a different technology. Starting with ActiveMQ 5.9 there is an option to use Replicated LevelDB with Zookeeper6.

SQS

SQS stores messages in redudant storage across all availability zones in a given region. To achieve high levels of redundancy and guarantee that no message is ever lost it relaxes some of the properties of a queueing system7. What that means is that on rare occasions messages may arrive out of order, and same message may be delivered more than once.

3. Graceful Failure

ActiveMQ

In a master-slave8 configuration all clients failover to the next available slave and continue processing messages. In any other configuration, all processing stops until the client is able to reconnect to its broker.

In the event of high memory, temp storage, or jounal space usage ActiveMQ can pause producers until the space frees up. This creates a potential for a deadlock situation where some consumers also act as publishers and become unable to publish or consume messages. There is a risk of the entire system locking up until space is freed up or configuration is changed.

SQS

When your application attempts to retrieve messages from a queue SQS picks a subset of all servers and returns messages from those servers. What that means is that if for some reason a server was unavailable a message may not get retrieved – but will on subsequent requests. This is mitigated to a certain extent by use of long polling9.

4. Message Order and Delivery Guarantee

ActiveMQ

Messages are delivered in the order they are sent10. When there are multiple consumers on the same queue some of the order may be lost – however, that is the case with any queue that has multiple consumers and it is exacerbated by clustering configurations.

SQS

In order to achieve high levels of scalability and redundancy SQS relaxes some of the guarantees of a traditional queuing system. On rare occasions messages may be delivered out of order and more than once, but they will get delivered and no message will be lost. Applications sensitive to duplicated or out-of-order processing need to implement logic to cover these scenarios11.

5. Monitoring and Utility API

This may seem off topic but I do find it necessary to mention. It is often useful, from application standpoint, to perform various utility functions against queues. An application may measure the rate of dequeuing, calculate number of pending messages, and self-optimize.

JMS does not offer API to retrieve this information. ActiveMQ does expose some of this via JMX, however12. Similarly, SQS offers metrics and utility API as part of the SDK.

6. Standards Compliance

ActiveMQ

ActiveMQ conforms to the JMS API specification in the Java universe and has drivers for other platforms and API specifications.

SQS

SQS uses HTTP REST protocol and a proprietary SDK. However, Amazon does offer a JMS implementation of the SQS SDK13.

7. Push Messages as They Become Available

ActiveMQ

The default ActiveMQ protocol is based on a socket connection that allows messages to get pushed to the consumer as soon as they are published. With JMS one can implement MessageListener14 interface and receive messages as they arrive.

SQS

SQS does not natively support push. One has to poll to retrieve messages. This is a minor inconvenience since Amazon provides both long polling and a JMS implementation. Various approaches exist to mimic the push behavior including one that I described in my post on “Guaranteeing Delivery of Messages with Amazon SQS.”15

8. Scalability and Performance

ActiveMQ

ActiveMQ can handle tens of thousands of messages per second on a single broker16. There is a great deal of tuning that affects ActiveMQ performance including the host computer capacity, network topology, etc. Scalability is achieved either vertically by upgrading broker hardware or horizontally by expanding the broker cluster.

SQS

SQS does not return from a SendMessage request unless the message has been successfully store and as a result it has a request-response latency of around 20ms. At first glance it may mean that it cannot handle more than a few hundred messages per second.

However, when dealing with a distributed queue like SQS one has to distinguish between latency and throughout17. SQS scales horizontally. By using multiple threads it is possible to increase message throughput almost indefinitely.

9. Setup, Operations and Support

ActiveMQ

ActiveMQ is just like any other software that one has to install, configure, monitor and maintain. Configuring and tuning ActiveMQ requires thorough understanding of hundreds of different settings18. ActiveMQ itself is written in Java so understanding of Java topics like memory management and garbage collection is helpful.

SQS

As long as you are operating in the AWS environment there is nothing to configure, install or maintain. SQS is a completely managed service.

10. Costs

ActiveMQ

ActiveMQ needs hosts to run on and storage it can use. Someone has to support and maintain it. The costs of ActiveMQ are a function of resources it needs to run and time it takes to tune, configure and maintain it. These costs are still present during periods of low utilization since it doesn’t scale automatically.

SQS

SQS is priced as a function of number of requests and data transfer. You are only charged for what you consume, so during periods of low utilization the costs are lower.

Conclusion

The discussion in this post boils down to the choice between a fully managed cloud service and an installable software product, just like DynamoDB vs Cassandra19. A managed service simplifies development and maintenance at the expense of standards compliance and customization options.
